Характеристики
- Бренд
- HUAQIZHENGBANG
- Применение
- SMT series
- Номер модели
- ZB3245T
- Mounting number
- 2pcs
- Mounting precision
- 0.05mm
- Mounting angle
- 0~360°
- Theoretical speed
- 6500PCS/h
- Normal mounting
- 5000PCS/h
- Nozzle type
- Juki series nozzle
- PCB minimal Size
- 10*10mm
- PCB maximum Size
- 320*450mm
- PCB thickness
- ≤2mm
- Preposition IC material level
- 8PCS
- X/Y axis moving range
- 410*490mm
- Z axis moving range
- 10mm
- Z axis rotation range
- 0~360°
- Operational software
- Embedded HRM system
- Compatible file format
- CSV.format
- Air pressure
- 0.4 Mpa
- Vacuity degree
- -92kpa
- Power
- 150W
- Power supply
- AC220V ±10% 50Hz
- Main engine outline size
- L800*W780*H380mm
- Materials feeder outline size
- L235*W700*H245mm
